Reverse Engineering

PCB Data Generation from just a loaded board.

• Network Listing.
• Bill Of Materials.
• Gerber Files and CAD Files.
• Schematics.
• Validation of existing Gerber Files.

Purposes for Reverse Engineering.

• To build a new board.
• Recovering from device obsolescence.

• A Docking Station (that typically stays on the tester) that consists of the kit, the pneumatic mechanisms, the hold-down   mechanism, PODs for device programming, vectorless mux card, etc.
• Cassette Fixture customized for each board, but consists of just wires, probes, vectorless modules, etc.
